[Stall torque]  4.8 (6.6V)/ 5.4 (7.4V)/ 6.1 (8.4V)kg・cm
                     65.8 (6.6V) / 74.9 (7.4V) / 85.1 (8.4V)oz・in
[Speed]         0.04 (6.6V)/0.03 (7.4V)/0.03 (8.4V) Sec/60°
[Weight]        63.8 g / 2.25 oz
[Measurement]  40 x 20 x 40.45 mm / 1.38 x 0.79 x 1.59 in
[Lead length]     300mm
[Volt range]       4.5V – 8.5V
[neutral]            760μSec.  (With the servo programmer it can be changed to 1500μSec. )
[herz] XBUS：1KHz / PWM：333Hz

■high performance brushless motor
■programmable（slow start：OFF）
■full metal gear
■full metal case
■wide voltage
■double ball bearing
■angle：120°/180°
※does not come with servo arm

Important Notes on Using Our Servos

Our servos are programmed to operate with high precision and sensitivity.
Because of this, if there are any obstructions within the servo’s range of motion and it is unable to move as commanded by the transmitter, the servo may experience excessive load. This can result in damage to the internal circuit board due to overheating.

When installing the servo for throttle, aileron, or other control surfaces, please make sure to leave a small amount of free play between the servo travel range and the mechanical movement range. This helps prevent any binding or overloading of the servo.
